MV-Plane

MV-Plane is a state-of-the-art software for NF/FF transformation in planar geometries combining both standard and advanced functionalities.

MV-Plane

BASIC PACKAGE

  • Planar NF/FF transformation
  • Theoretical Probe Correction
  • Gain Calculation (Substitution & direct methods)

ADVANCED PACKAGE

  • Planar Back projection
  • Custom probe correction
  • Frequency drift compensation for on-the-fly axis
  • AUT rotation & translation

KEY-BENEFITS

  • Standard functionalities are based on solid and well established theory
  • Fast and accurate processing based on Plane Wave Spectrum (PWS) computation
  • User-friendly GUI with preview of the results
  • Advanced functionalities to virtually rotate / translate after measurements & to obtain diagnostic information (Planar back propagation)
