多探针系统
650 MHz - 50000 MHz
20 多年来，MVG StarLab 以其紧凑的占地面积、测量可靠性和直观的操作方式，为全球数百家公司和研究实验室提供了支持。从卫星天线开发到物联网和 5G 测试，它帮助加速了各行各业的创新，而不会受到任何影响。随着测试要求的发展，频率越来越高，设备集成度越来越高，软硬件之间的联系越来越紧密，因此需要一种新的方法。
全新 StarLab 产品系列简介：完全集成的 OTA 和无源多探针测试系统系列，专为满足当今需求和适应未来挑战而打造。
* 满足从基本验证到国防级研发的测试需求
* 提供为您的工作流程量身定制的模块化软件包
* 支持灵活、可扩展的配置，以满足您的需求
根据您的需求选择合适的系统--自信地加快测试速度！
StarLab 产品组合中的每个系统都具有与您的目标相匹配的特定功能。
6 款机型供您选择
满足您的需求
参考文献
StarLab Core
Affordable OTA Testing Made Easy
Frequency : 650 MHz - 8 GHz
Number of probes : Half arch - Single array : 8 x Low Frequency(LF) probes
Total: 8 probes
Probe angle : 22.5°
Geometry : Spherical
Absorbers : Non-rubberized
Software: Delivered with PASSIVE-Essential, OTA Mobile Cellular - Essential (LTE)
Software Options : OTA-IoT-Essential (WIFI & BT); Dev-Mode: ONS-UL only
StarLab Core +
All-in-One OTA & Passive Testing up to 11 GHz
Frequency : 650 MHz – 11GHz*
(*) 10 GHz for passive, 11 GHz for OTA
Number of probes : Full arch - Single probe array: 15 x Low Frequency(LF) probes (650 MHz - 11 GHz)
Total : 15 probes
Probe angle : 22.5°
Geometry : Spherical and/or Cylindrical
Absorbers : Rubberized
Software : Delivered with PASSIVE-Essential, OTA Mobile Cellular-Advanced (NR)
Software Options : PASSIVE-Advanced ; OTA-IoT (Essential & Advanced); Dev-Mode: ONS-UL & API
StarLab PRO
Versatile Platform for R&D Below 18 GHz
Frequency : 650 MHz – 18GHz
Number of probes: Full arch - Interleaved : 15 x Low Frequency(LF) probes (650MHz - 11GHz) + 14 x High Frequency(HF) probes (11GHz - 18GHz)
Total : 29 probes
Probe angle : 22.5°
Geometry : Spherical and/or Cylindrical
Absorbers : Rubberized
Software : Delivered with PASSIVE-Advanced ; Developer Mode (OTA Non-signaling Uplink & API)
Software Options : Full OTA (Essential & Advanced) ; Developer Mode : OTA Non-signaling Downlink
StarLab PRO +
40 GHz Test Power Without Compromise
Frequency : 650 MHz – 40 GHz
Number of probes : Full arch - Interleaved : 14 x Low Frequency(LF) probes (650MHz - 11GHz) + 15 x Ultra High Frequency(UHF) probes (11GHz - 40GHz)
Total : 29 probes
Probe angle : 22.5 °
Geometry : Spherical and/or Cylindrical
Absorbers : Rubberized
Options : On the fly measurement capabilities
Software : Delivered with PASSIVE-Advanced ; Developer-Mode : OTA Non-signaling Uplink & API
Software Options: Full OTA (Essential & Advanced) ; Developer-Mode : Non-signaling Downlink
StarLab ULTRA WB
The Ultimate Test System for Defense and Innovation
Frequency : 650 MHz - 50 GHz
Number of probes : Full arch - Half-Half : H1 : 7 x Low Frequency(LF) (650MHz-11GHz) + 7 x High Frequency(HF) (11GHz-18GHz); H2 : 15 x Ultra High Frequency (UHF) (18GHz - 50GHz)
Total : 29 probes
Probe angle : 22.5° for LF & HF ; 11.25° for UHF
Geometry: Spherical
Absorbers : Rubberized / Dark Grey /
Options : On the fly measurement / US Defense grade / Rentable /Logo on Styrofoam CAP in the chamber or absorber wall*
Software : Delivered with PASSIVE-Advanced, OTA Mobile Cellular-Advanced, Insight, Developer Mode (OTA Non-signaling Uplink & API)
Software Options : OTA-IoT (Essential & Advanced) ; Developer Mode : OTA Non-signaling Downlink
* Custom color for absorbers possible
StarLab ULTRA - Passive
The Ultimate Test System for Defense and Innovation
Frequency : 18 GHz - 50 GHz
Number of probes : Full arch - Single probe array : 29 x Ultra High Frequency (UHF) (18GHz - 50GHz)
Total : 29 probes
Probe angle : 11.25°
Geometry : Spherical
Absorbers : Rubberized
Options : On the fly measurement / US Defense grade / Rentable /Logo on Styrofoam CAP in the chamber or absorber wall*
Software : Delivered with PASSIVE-Advanced, Insight, Developer Mode (OTA Non-signaling Uplink & API)
Software Options : Developer Mode : OTA Non-signaling Downlink
* Custom color for absorbers possible
